Key Features

NVIDIA Ampere Streaming Multiprocessors

2nd Generation RT Cores

3rd Generation Tensor Cores

Powered by GeForce RTX™ 3050

Integrated with 8GB GDDR6 128-bit memory interface

WINDFORCE Cooling System

90mm unique blade fan



CORE CLOCK

1792 MHz (Reference Card: 1777 MHz)



WINDFORCE COOLING SYSTEM

The WINDFORCE cooling system features two 90mm unique blade fans, the heatpipe directly touches the GPU, alternate spinning and 3D active fan, which together provide high efficiency heat dissipation.



ALTERNATE SPINNING

Reduce the turbulence of adjacent fans and increase air pressure. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.



UNIQUE BLADE FAN

The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.



3D ACTIVE FAN

The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.



GRAPHENE NANO LUBRICANT

Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.



ULTRA COOLING

Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.



LOW POWER LOSS

Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.



LONGER LIFE

Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.



FRIENDLY PCB DESIGN

Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.



Specifications



Graphics Processing

GeForce RTX 3050



Core Clock

1792 MHz (Reference Card: 1777 MHz)



CUDA Cores

2560



Memory Clock

14000 MHz



Memory Size

8 GB



Memory Type

GDDR6



Memory Bus

128 bit



Card Bus

PCI-E 4.0



Digital max resolution

7680 x 4320



Multi-view

4



Card size

L=198.1 x W=120.6 x H=39 mm



PCB Form

ATX



DirectX

12 Ultimate



OpenGL

4.6



Recommended PSU

450W



Power Connectors

8 pin x 1



Output

DP1.4a x 2

HDMI 2.1 x 2



Accessories

Quick guide
