The H5 Flow RGB boosts airflow and GPU cooling with its perforated PSU shroud, mesh panels, and large radiator support—all in a compact mid-tower form factor.
- The PSU shroud is perforated on the side and bottom, enabling optimal air intake from two 120mm fans (not included).
- Supports up to a 360mm radiator in front and a 240mm radiator up top for powerful liquid cooling potential.
- Ultra-fine mesh on the top, front, and side panels creates maximum airflow and filters dust.
- Equipped with a front-mounted F360 RGB Core (CV) single-frame fan and rear-mounted F120Q (CV) fan for strong out-of-the-box cooling and lighting.
- Effortlessly route and conceal cables using the wide channels, hooks, and straps.
Product Name:
+NEW+NZXT H5 Flow RGB Mid Tower Case White (E-ATX/ATX/M-ATX/M-ITX)
Web Address:
Model Number:
CC-H52FW-R1
EAN:
5056547205861
Package Type:
Retail
Warranty:
2 Years
Case Type:
Mid Tower
Colour:
White
Material Chassis:
SGCC Steel
Side Panel:
Tempered Glass
Front USB 3.2 Gen 1 Port(s) Type-A:
1
Front USB 3.2 Gen 2×2 Port(s) Type-C:
1
Front Headphone Jack(s):
1
Expansion Slots:
7
Motherboard Support:
Mini ITX / Micro ATX / ATX / E-ATX
Drive Bays Internal 3.5″:
1
Drive Bays Internal 2.5″:
2
Pre-installed Fan(s) Front:
1 x F360 RGB Fan
Pre-installed Fan(s) Rear:
1 x F120Q Fan
Radiator Support:
- Front: Up to 360mm
- Top: Up to 240mm (280mm with low-profile memory only)
Fan Support:
- Front: 3 x 120mm / 2 x 140mm
- Top :2 x 120mm / 2 x 140mm
- Bottom: 2 x 120mm
- Rear: 1 x 120mm
Clearances:
- CPU Cooler Height: Up to 170mm
- GPU Length: Up to 410mm
- PSU Length: Up to 200mm
- Cable Management: Up to 28.7mm
- Top Radiator: Up to 240mm (280mm with low-profile memory)
- Top Mounted 140mm / 280mm Radiator and Fan Combined Thickness:Up to 55 mm
Product Width:
225mm
Product Length:
430mm
Product Height:
465mm
Product Weight:
7630g
Special Features:
- The H5 Flow RGB boosts airflow and GPU cooling with its perforated PSU shroud, mesh panels, and large radiator support – all in a compact mid-tower form factor.
- The PSU shroud is perforated on the side and bottom, enabling optimal air intake from two 120mm fans (not included).
- Supports up to a 360mm radiator in front and a 240mm radiator up top for powerful liquid cooling potential.
- Ultra-fine mesh on the top, front, and side panels creates maximum airflow and filters dust.
- Equipped with a front-mounted F360 RGB Core (CV) single-frame fan and rear-mounted F120Q (CV) fan for strong out-of-the-box cooling and lighting.
- Effortlessly route and conceal cables using the wide channels, hooks, and straps.
- E-ATX (Up to 277 mm wide)
Package Contents:
- H5 Flow RGB
- 1 x F360 RGB Core
- 1 x F120Q
- Installation Accessories
- User Guide
