Series
Samsung 990 EVO PLUS
Capacity
2 TB
Form Factor
M.2 2280
Interface
PCIe 4.0 x4 / 5.0 x2
Controller
Samsung in-house Controller
Read
Up to 7250 MB/s
Write
Up to 6300 MB/s
Max Random 4K R/W
1000K / 1350K IOPS
Power Consumption
Average: Read 4.6 W / Write 4.2 W
Idle: Typical 60 mW
Device Sleep: Typical 5mW
Weight/Dimensions
9g
80.15 x 22.15 x 2.38 mm
Operating Temperatures
0 – 70°C
Shock Resistance
1,500 G & 0.5 ms (Half sine)
Vibration Non-operating
20~2,000Hz, 20G
MTBF
1.5 Million Hours
Total Bytes Written (TBW)
1200 TBW
Additional Features
See Overview
Package Type
Retail
Package Weight
0.0760 kg
Warranty
5 Years or if the drive exceeds Total Bytes Written (see above)
Full Box Quantity
10
